Water Pressure Sensor

Introduction

CW4 Model pressure sensor are specially developed for air flow pressure systems. Such as in gas fired heating systems. Or ensuring ventilation in heat pumps or ensuring the exhaust air flow in pellet boilers and gas boilers. HVAC, Energy Management, Food Service, Comfort and Recreation, and Facility Management are a few of the industries served by this switches.

Specifications

Body

Glass filled polyester

Diaphragm

Silicon

Terminals

Brass 4.8X0.5mm

Contacts

Golden plated

Switch Type

SPST-NO Only

Life

100,000 Cycles

Max Operating Pressure

3000Pa

Port Connection

6.3mm O.D

Working Pressure Range

-20Pa~+200Pa(Customerlized)

Operating Position

Diaphragm vertical

Operating Temperature

-30°C ~ +85°C

Deviation of Setting

±5pa

Medium

Air or neutral gases
